MLT18 – Dynamic mechanical load tester
The MLT18 is our basic dynamic mechanical load test stand (DML). It simulates static and dynamic loads and is suitable for load testing according to international standards for modules of typical size. 18 pneumatic cylinders with four vacuum suction cups each, exert both compressive and tensile loads on the test sample.
The MLT18 is an excellent product for basic testing. The manual test setup and adjustment is accomplished quickly and easily. Cylinders are activated or deactivated with manual ball valves and can be positioned individually to achieve any desired (even non-uniform) suction cup arrangement.
The software features an intuitive user interface that allows complete remote control of the test stand. It supports dynamic testing according to IEC standards and makes it easy to create customized test schedules that can be defined, saved, and reused at any time. Key measurements are displayed in real time, and the planned test sequence is presented in a clear and structured way.
Technical specifications
| Test area | 2.6 m × 1.4 m |
|---|---|
| Simultaneous testing capacity | 1 |
| Number of pneumatic cylinders | 18 |
| Number of suction cups at one piston | 4 |
| Maximum total force with all cylinders | Push +20,7 N Pull -15,7 N |
| Load cycle frequency | 0.1 Hz |
| Number of deflection sensors | 1 (optional 8) |
| Relevant standards | IEC 61215, IEC 61646, IEC 62782, UL 1703, ISO 9806, EN 12975 |
Key facts
- Fast adjustment for testing units of different sizes with sliding cross bars and quick release levers
- High precision load measurement and continuous monitoring of load distribution by using on load cell per cylinder
- Static and dynamic load testing according to common international standards
- Applicable forces up to +20.7 kN / -15.7 kN
- Highly accurate deflection measurement of the unit under test by optical distance sensors
- Electrical continuity measurement for PV modules available
- Integrated machine enclosure with door lock for safe operation on minimum footprint
Software features
- Intuitive graphical user interface for full remote control of the test stand
- Dynamic testing according to IEC standards
- Customized test schedules (even non-cyclic, free definition of various load setpoints can be saved and restored)
- Real-time visualization of key measurements in graphical displays
- Visual depiction of the planned test progress
